Synthetic Standard Sleeping Mats

Description

Synthetic sleeping mats are used to sleep on and must be waterproof, tear proof and material trim finished.

Technical Specifications

Material The mats should be made from 100% synthetic yarns from virgin raw materials.

Synthetic sleeping mats must not contain fillers, like calcium carbonate or any other type. The use of recycled materials is not allowed.

The synthetic yarns in a tightly woven 2/2 twill structure, using a monofilament or multifilament warp (PP tubes without fillers minimum 1000 tubes per meter length) and thick tape PP or polyester yarn in weft. The two short sides to be secured with a first stitch folded hem of the mat, plus one bias 40mm binding tape of minimum 10g/m with stitches through the fabric of the mat, OR with a double folded stitched hem. Four sides trim finished.

Logos and colours available as per customer requirements subject to minimum order quantity.

Specifications Bursting Strength under ISO13938: 700 kPa minimum.
Tear Strength: The edges of the mat should not be tearable when strongly pulled outside by hand or other similar force.
Dimensions 1.8 x 0.9m minimum, area 1.62m2; or
1.8 x 2.7m minimum, area 4.86 m2
Weight 0.500 kg/m2 minimum ±5%.

Packing & Loadability

1.8 x 0.9m sleeping mats

Packing, Weight & Volume
Packing: 25 pieces to be in a package to be wrapped in a protective outer PP woven canvas, with 4 straps. No individual packing required.
Gross weight per piece: 0.769 to 0.8505 kg approx.
Gross weight per bale: 19.2 to 21.5 kg
Bale size: approx. 92 x 40 x 50 cm (L x W x H)

Loadability

20′ DC 40′ DC 40′ HC
With pallet 3,300 pcs 6,900 pcs 6,900 pcs
Without pallet 5,500 pcs 11,000 pcs 13,500 pcs



1.8 x 2.7m sleeping mat

Packing, Weight & Volume
Packing: 15 pieces to be in a package to be wrapped in a protective outer PP woven canvas, with 4 straps. No individual packing required.
Gross weight per piece: 2.43 kg approx.
Gross weight per bale: 36.5 kg
Bale size: approx. 92 x 40 x 50 cm (L x W x H)
